Category
Embedded - DSP (Digital Signal Processors)
Manufacturer
Freescale / NXP Semiconductors
RoHS
YES
Certification
Delivery
Payment
| TYPE | DESCRIPTION |
| Part Number: | XC56309VF100A |
| Description: | IC DSP 24BIT FIXED-POINT 196-BGA |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Mounting Type | Surface Mount |
| Non-Volatile Memory | ROM (576 B) |
| Package / Case | 196-LBGA |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| On-Chip RAM | 24kB |
| Voltage - I/O | 3.30V |
| Interface | Host Interface, SSI, SCI |
| Supplier Device Package | 196-MAPBGA (15x15) |
| Clock Rate | 100MHz |
| Voltage - Core | 3.30V |
| Packaging | Tray |
| Meta Part Number | XC56309VF100A-ND |
| Type | Fixed Point |
| Series | DSP563xx |
| Base Part Number | XC56309 |
| Operating Temperature | -40°C ~ 105°C (TJ) |
Data sheet: Work in prgress, stay tuned!
