Category
Mobile Platform
Manufacturer
Vkoming
RoHS
YES
Certification
Delivery
Payment
| CPU | Intel®8th/10th Whiskey lake-U&Coffeelake-U&Cometlake Processor |
| Chipset | Intel® SOC |
| Memory | 2*SO-DIMM DDR4 3200MHz Max 64GB |
| Storage | 1*SATA3.0 / 1*M.2 Key M (Supports Sata&PCIe NVMe SSD adaptive) |
| Expansion Interface | 1*Mini PCIe (Supports Wifi+Bluetooth /4G expansion modules) 1*SIM card slot |
| BIOS | AMI BIOS |
| System | Windows 10/11 32bit/64bit/Linux |
| Ethernet | 1/2*Realtek® RTL8111 1Gbps Ethernet Controller,RJ45 |
| Serial | 4*COM232 (COM1 supports RS232/485 as an option) |
| USB | 4*USB 3.0,3/5*USB 2.0 |
| Audio | Onboard audio decoding controller ALC897 + NS4251 default power amplifier support 3 w @ 4 Ω; 1.7W@8Ω max |
| Others | 1*SATA interface / 1*SATA_PWR Header / 4*COM232 Header |
| Display Interface | 2*HDMI / 1*DP (Support 3 display synchronous/asynchronous output) |
| Dimension | 121mmX121mm |
| Power Input | DC 12V-19V input power supply |
| Temperature | Operation: 0℃~60℃, Storage: -20℃~75℃ |
| Relative Humidity | 0% ~ 95%, non-condensing |
Data sheet: Work in prgress, stay tuned!
