G240HW01 V1
G240HW01 V1
G240HW01 V1
G240HW01 V1
G240HW01 V1
  • AUO G240HW01 V1
  • AUO G240HW01 V1
  • AUO G240HW01 V1
  • AUO G240HW01 V1
  • AUO G240HW01 V1
G240HW01 V1
Size
24"
Resolution
1920×1080
CR
5000:1
Brightness
300
Interface
LVDS
Max Ratings
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
Certification
ISO14001:2015 Certification ISO 45001:2018 Certification ISO 9001:2015 Certification
Delivery
Delivery
Payment
Payment

{{title}}
Price not available? Fill in the information below to send a quick RFQ, and we will respond promptly
{{ isClicked ? 'Submitted' : 'Submit RFQ' }}

G240HW01 V1 24-Inch Industrial TFT LCD Display Module

The G240HW01 V1 delivers sharp Full HD resolution with excellent color uniformity and wide viewing angles. Its high-brightness panel and long-life LED backlight make it ideal for demanding industrial environments requiring reliable and clear displays. With LVDS interface and flexible mounting options, G240HW01 V1 integrates seamlessly into industrial PCs, control panels, medical devices, and embedded automation systems.

Specifications
Data Sheet
Advantages
Solutions

1.Decades of Experience

Supplying LCD displays since 1998, ANDE Electronics has built extensive expertise and a reliable network of manufacturers, ensuring high-quality components and solutions.

2.Wide Inventory

We stock LCD displays ranging from 1.3’’ to 65’’, ready for immediate delivery to meet both small-scale and large-scale project needs.

3.Hard-to-Find LCD Stock

Discontinued modules are often difficult to source. ANDE Electronics provides access to hard-to-find LCD stock, helping clients complete projects without delays.

4.Solution Support

Our team assists with LCD screen selection and integration, offering guidance to make sure the right display fits your project requirements.

5.Technical Services

We offer enhancements and add-ons such as touch screen overlays, driver boards, and highlighted features.

6.LCD Touch Sreen Customization

ANDE Electronics provides custom touch solutions, allowing clients to upgrade standard LCD modules with touch functionality tailored to specific applications.

Solutions overview / Healthcare / Manufacturering / New energy / Enterprise

Medical display solutions (12.1"/15"/17"/19"/21.5")

Panel size: 12.1 inches, 15.0 inches, 17.0 inches, 19.0 inches, 21.5 inches

Resolution: 800*600, 640*480, 1024*768

Brightness: 350nit, 400nit, 500nit, 600nit, 700nit

Supported colors: 262K/16.7M 262K/16.2M

Working temperature: -30 ~70°C -20 ~70°C 0 ~ 50 °C

Touch mode: Resistive screen

Interface: LVDS (supports HDMI adapter board)

Representative solutions: RK3588, RK3568, RK3288, JETSON, Intel H610/Q670, etc.

Industrial 10.4"/12.1"/15" financial/industrial control monitor

Panel size: 10.4 inches, 12.1 inches, 15 inches

Resolution: 640*480, 1280*800, 1024*768

Brightness: 350nit, 400nit, 550nit, 1000nit, 1500nit

Supported colors: 262K/16.2M

Working temperature: -30 ~ 80 °C -30 ~ 70 °C -20 ~ 70 °C

Touch mode: Resistive screen Capacitive screen

Interface: LVDS, TTL (supports HDMI adapter board)

Representative solutions: RK3588, RK3568, RK3288, JETSON, Intel H610/Q670, etc.

Product Overview

  • The AUO G240HW01 V1 is a 24-inch Full HD industrial TFT LCD module designed for industrial display applications requiring high contrast, reliable digital connectivity and a large-format 16:9 display.
  • With a native 1920 × 1080 resolution, G240HW01 V1 provides Full HD image reproduction for industrial PCs, control terminals, embedded systems, professional monitors and other display equipment.
  • The panel provides 300 cd/m² typical luminance and a 5000:1 typical contrast ratio. The VA, normally-black display technology provides deep black levels and strong contrast for clear image presentation.
  • G240HW01 V1 uses a dual-channel LVDS interface and supports 16.7M colors with true 8-bit input. The integrated LED driver simplifies backlight integration and reduces the need for an external LED driving solution.
  • The module has an active display area of approximately 531.36 × 298.89 mm and a mechanical size of approximately 556.0 × 323.2 × 17.0 mm. Its anti-glare 3H surface treatment provides improved surface durability and helps reduce reflections in professional operating environments.

Key Features

24-Inch Industrial TFT LCD
  • Provides a large 24-inch display area for industrial PCs, control panels, professional monitors and embedded equipment.
Full HD 1920 × 1080 Resolution
  • Provides detailed Full HD image reproduction with a 16:9 widescreen format, making it suitable for modern industrial and professional display systems.
5000:1 High Contrast Ratio
  • Provides strong differentiation between dark and bright image areas for clear image presentation and improved visual depth.
300 cd/m² Brightness
  • Provides suitable luminance for indoor industrial equipment, control terminals and professional display systems.
VA Normally-Black Display Mode
  • Uses VA display technology with a normally-black mode to provide high contrast and strong black-level performance.
Wide Viewing Angle
  • Provides wide viewing performance of approximately 89° in four directions under the specified contrast-ratio condition.
Dual-Channel LVDS Interface
  • Uses a dual-channel LVDS digital interface for reliable high-speed image signal transmission and system integration.
True 8-Bit Color
  • Supports 16.7M colors with true 8-bit RGB data for smooth color reproduction.
LED Backlight
  • Uses an LED backlight system with an integrated LED driver board for simplified system integration.
Anti-Glare 3H Surface
  • Features an anti-glare surface with 3H hard coating to reduce reflections and improve surface durability.
Wide Operating Temperature
  • Supports an operating temperature range of -20°C to +70°C for industrial and professional display applications.
RoHS Compliant
  • The G240HW01 V1 specification identifies the module as RoHS compliant.
Large Active Display Area
  • Provides an active display area of approximately 531.36 × 298.89 mm for a spacious Full HD viewing experience.

Applications

Industrial PC Displays
  • Suitable for industrial computers, panel PCs and embedded computing platforms requiring a 24-inch Full HD display.
Industrial Control Systems
  • Applicable to industrial control terminals, machine interfaces and automation equipment.
Factory Automation
  • Suitable for production-line equipment, automation systems and operator control stations.
Industrial HMI
  • Provides a large Full HD display solution for human-machine interface applications.
Professional Monitoring Systems
  • Suitable for monitoring terminals and professional control systems requiring a large-format display.
Medical Equipment
  • Applicable to selected medical equipment, healthcare terminals and professional monitoring systems where the module's electrical and optical specifications meet system requirements.
Embedded Display Systems
  • Suitable for OEM equipment requiring a 24-inch Full HD TFT LCD with LVDS connectivity.
Security and Surveillance Equipment
  • Applicable to surveillance terminals, security monitoring systems and professional display equipment.
Transportation Equipment
  • Suitable for selected transportation control and monitoring systems requiring a large-format industrial display.
Measurement and Inspection Equipment
  • Applicable to industrial testing equipment, inspection systems and measurement instruments.
Energy and Power Equipment
  • Suitable for monitoring terminals and control equipment used in energy and power applications.
OEM and ODM Display Projects
  • Suitable for display replacement, new product development, LCD integration and customized industrial display projects.

Why Choose Andesource

  • Professional supplier of industrial LCD displays and embedded modules
  • Original AUO LCD module sourcing
  • Global sourcing and supply chain support
  • Engineering and integration assistance
  • Technical documentation available
  • LCD replacement and cross-reference solutions
  • Flexible order quantities
  • Competitive pricing for OEMs and distributors
  • Fast international shipping
  • OEM and ODM customization support

FAQ

What is the G240HW01 V1 LCD module?
  • G240HW01 V1 is a 24-inch AUO industrial TFT LCD module designed for industrial display applications, embedded systems, industrial PCs and professional equipment.
What is the screen size of G240HW01 V1?
  • G240HW01 V1 has a 24-inch diagonal screen size.
What is the resolution of G240HW01 V1?
  • The native resolution is 1920 × 1080 pixels, which is Full HD.
What is the aspect ratio of G240HW01 V1?
  • The display uses a 16:9 widescreen format.
What is the brightness of G240HW01 V1?
  • The typical white luminance is 300 cd/m².
What is the contrast ratio of G240HW01 V1?
  • The typical contrast ratio is 5000:1.
What display technology does G240HW01 V1 use?
  • G240HW01 V1 uses VA display technology with a normally-black display mode.
What is the viewing angle of G240HW01 V1?
  • The typical viewing angle is approximately 89° in four directions under the specified CR ≥ 10 condition.
What interface does G240HW01 V1 use?
  • The module uses a dual-channel LVDS digital interface.
Does G240HW01 V1 support 8-bit color?
  • Yes. The module supports 16.7M colors using true 8-bit RGB data.
What type of backlight does G240HW01 V1 use?
  • The module uses an LED backlight and includes an LED driver board.
What is the operating temperature of G240HW01 V1?
  • The operating temperature range is -20°C to +70°C.
What is the storage temperature range of G240HW01 V1?
  • The storage temperature range is -30°C to +80°C.
What is the active area of G240HW01 V1?
  • The active display area is approximately 531.36 × 298.89 mm.
What are the dimensions of G240HW01 V1?
  • The module dimensions are approximately 556.0 × 323.2 × 17.0 mm.
Does G240HW01 V1 have an anti-glare surface?
  • Yes. The module uses an anti-glare surface treatment with 3H hard coating.
Is G240HW01 V1 suitable for industrial applications?
  • Yes. AUO specifies G240HW01 V1 as a display designed for industrial display applications. Its Full HD resolution, high contrast ratio, LVDS interface and -20°C to +70°C operating temperature range make it suitable for a variety of professional systems.
Can G240HW01 V1 be used in an industrial PC?
  • Yes. The 24-inch Full HD format and dual-channel LVDS interface make G240HW01 V1 suitable for compatible industrial PCs and embedded computer systems.
Can Andesource provide G240HW01 V1?
  • Andesource currently lists G240HW01 V1 as a 24-inch industrial TFT LCD and provides RFQ-based sourcing support.
Can Andesource provide a replacement or cross-reference solution?
  • Yes. Andesource can evaluate replacement and cross-reference LCD options based on size, resolution, interface, dimensions, brightness, contrast ratio and other system requirements.
Can Andesource support OEM and ODM display projects?
  • Yes. Andesource provides LCD sourcing, replacement evaluation, engineering assistance, touch integration and customized display solutions.
