The HTN7G09S060P is a high-performance discrete RF power amplifier designed with advanced LDMOS technology. With an saturated output power of 60 Watts, it operates effectively across a wide frequency spectrum from 700 MHz to 960 MHz. Its unmatched discrete design provides flexibility and easy integration, making it suitable for various RF infrastructure solutions, particularly in cellular communication systems and remote radio units (RRUs).

As one of ANDESOURCE’s Holto RF chip alternative solutions, the HTN7G09S060P serves as an alternative to the MRFE6S9045NR1. It offers over 50% cost savings, a steady supply, and debugging support directly from the original factory.

Now, let’s take a closer look at the key specifications, standout features, and applications of the HTN7G09S060P.

Key Specifications Overview

(Contact us for a quote.)

Standout Features Analysis

Broad Frequency Coverage and High Gain

The HTN7G09S060P operates over a 700-960 MHz frequency range, aligning with key telecom bands. With a gain of 21.0 dB to 22.1 dB depending on frequency, it delivers strong signal amplification, contributing to reliable RF performance in high-density communication environments.

Enhanced Robustness and Reliability

The HTN7G09S060P demonstrates high durability, successfully withstanding VSWR mismatches of 10:1 at 100W CW signals without degradation. Its built-in ESD protection (HBM: Class 1B, MM: Class A, CDM: Class III) enhances reliability, reducing risks during handling and integration.

Thermal Efficiency and Stability

With a low junction-to-case thermal resistance of 0.95 °C/W, the HTN7G09S060P offers efficient heat dissipation, contributing to stable performance under extended operation. This thermal design supports reliability in demanding telecom infrastructure applications.

Industry-Standard VDD of 28V

Operating at a +28V VDD, the HTN7G09S060P aligns with industry standards, enabling seamless integration into telecom infrastructure. This voltage compatibility helps simplify power supply considerations for RF engineers and system designers.

RoHS Compliant

The HTN7G09S060P meets RoHS compliance standards, restricting hazardous substances for safer environmental practices. This compliance supports global market adoption and regulatory alignment.

Application Analysis

The versatile design of the HTN7G09S060P positions it ideally for multiple RF applications, especially in modern telecom infrastructures:

RF Base Stations and MACRO RRUs

Designed for MACRO Remote Radio Units, the HTN7G09S060P provides high-performance signal amplification, supporting network stability even under varying conditions. Its robust design helps maintain reliable communication services in demanding environments.

Compatibility with Multiple Wireless Standards

With its 700-960 MHz frequency range, the HTN7G09S060P supports various wireless communication standards:

CDMA and W-CDMA – Compatible with both legacy and existing 3G networks.

GSM EDGE and MC-GSM – Supporting both legacy GSM networks and continued expansion in select regions.

TDD/FDD LTE – Enables high-speed data transmission for modern LTE applications.

WiMAX – Extends usability into broadband wireless access.

By supporting multiple standards, this amplifier enhances operational efficiency and cost-effectiveness for network operators and equipment manufacturers.

ANDESOURCE: Cost-Effective RF Chip Alternative Without Compromising Performance

For businesses seeking cost-effective alternatives for premium RF chip brands, ANDESOURCE’s RF chip alternative solutions offer the perfect combination of affordability, reliability, and high performance.

Why Choose ANDESOURCE’s RF Chip Alternative Solutions?

Over 50% Cost Savings – Reduce procurement costs significantly while maintaining top-tier performance.

Steady Supply – Ensure continuous production with a stable and reliable supply chain.

Direct Debugging Support – Get expert technical assistance directly from the original factory.

Excellent Performance – Designed to meet the same high standards as premium brands.

With ANDESOURCE, you don’t have to compromise between cost and quality—you get both. Contact us today to explore our RF chip alternative solutions and start saving without sacrificing performance.
